| Model | SUN-7K-G02P1-EU-AM2 | SUN-7.5K-G02P1-EU-AM2 | SUN-8K-G02P1-EU-AM2 |
| PV String Input Data |
| Max. PV Input Power (kW) | 10.5 | 11.3 | 12 |
| Max. PV Input Voltage (V) | 550 |
| Start-up Voltage (V) | 80 |
| MPPT Voltage Range (V) | 70-500 |
| Rated PV Input Voltage (V) | 360 |
| Max. Operating PV Input Current (A) | 18+26 |
| Max. Input Short Circuit Current (A) | 27+39 |
| No. of MPP Trackers/No. of Strings per MPP Tracker | 2/1+2 |
| AC Output Side |
| Rated AC Output Active Power (kW) | 7 | 7.5 | 8 |
| Max. AC Output Apparent Power (kVA) | 7.7 | 8.25 | 8.8 |
| Rated AC Output Current (A) | 31.9/30.5 | 34.1/32.7 | 36.4/34.8 |
| Max. AC Output Current (A) | 35/33.5 | 37.5/35.9 | 40/38.3 |
| Rated Output Voltage/Range (V) | 220/230 0.85Un-1.1Un |
| Grid Connection Form | L/N/PE |
| Rated Output Grid Frequency/Range(Hz) | 50/45-55, 60/55-65 |
| Power Factor Adjustment Range | 0.8 leading to 0.8 lagging |
| Total Current Harmonic Distortion THDi | <3% |
| DC Injection Current | <0.5% |
| Efficiency |
| Max.Efficiency | 97.70% |
| Euro Efficiency | 97.20% |
| MPPT Efficiency | >99% |
| Equipment Protection |
| DC Polarity Reverse Connection Protection | Yes |
| AC Output Overcurrent Protection | Yes |
| AC Output Overvoltage Protection | Yes |
| AC Output Short Circuit Protection | Yes |
| Thermal Protection | Yes |
| DC Terminal Insulation Impedance Monitoring | Yes |
| DC Component Monitoring | Yes |
| Ground Fault Current Monitoring | Yes |
| Arc Fault Circuit Interrupter (AFCI) | Optional |
| Power Network Monitoring | Yes |
| Island Protection Monitoring | Yes |
| Earth Fault Detection | Yes |
| Overvoltage Load Drop Protection | Yes |
| Residual Current (RCD) Detection | Yes |
| Surge Protection Level | TYPE II(DC), TYPE II(AC) |
| Interface |
| Communication Interface | RS485/RS232 |
| Monitor Mode | GPRS/WIFI/Bluetooth/4G/LAN(optional) |
| General Data |
| Operating Temperature Range (°C) | -25 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity | 0-100% |
| Permissible Altitude (m) | 3000m |
| Noise (dB) | ≤35 |
| Ingress Protection(IP) Rating | IP 65 |
| Inverter Topology | Non-Isolated |
| Over Voltage Category | OVC II(DC), OVC III(AC) |
| Cabinet Size (WxHxD mm) | 330×310×208.5(Excluding Connectors and Brackets) |
| Weight (kg) | 12.1 |
| Warranty | 5years |
| Type of Cooling | Natural Cooling |
| Grid Regulation | IEC 61727, IEC 62116, EN 50549, NRS 097, RD 140, UNE 217002, G99 |
| Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
